Sensing Module Type (Parameter 222)
The E300 relay offers 12 different sensing modules. Place the value of the
expected sensing module into Parameter 222. A value of (0) disables the Option
Match feature for the sensing module.
Table 33 - Sensing Module Type (Parameter 222)
Communication Module Type (Parameter 223)
The E300 relay offers two different communication modules. Place the value of
the expected communication module into Parameter 223. A value of (0) disables
the Option Match feature for the communication module.
Table 34 - Communication Module Type (Parameter 223)
Code Description Sensing Module Cat. No.
0 Ignore —
1 Voltage / Current 0.5…30 A / Ground Fault 193-ESM-VIG-30A-__ or 592-ESM-VIG-30A-__
2 Voltage / Current 6…60 A / Ground Fault 193-ESM-VIG-60A-__ or 592-ESM-VIG-60A-__
3 Voltage / Current 10…100 A / Ground Fault 193-ESM-VIG-100A-__ or 592-ESM-VIG-100A-__
4 Voltage / Current 20…200 A / Ground Fault 193-ESM-VIG-200A-__ or 592-ESM-VIG-200A-__
5 Current 0.5…30 A / Ground Fault 193-ESM-IG-30A-__ or 592-ESM-IG-30A-__
6 Current 6…60 A / Ground Fault 193-ESM-IG-60A-__ or 592-ESM-IG-60A-__
7 Current 10…100 A / Ground Fault 193-ESM-IG-100A-__ or 592-ESM-IG-100A-__
8 Current 20…200 A / Ground Fault 193-ESM-IG-200A-__ or 592-ESM-IG-200A-__
9 Current 0.5…30 A 193-ESM-I-30A-__ or 592--ESM-I-30A-__
10 Current 6…60 A 193-ESM-I-60A-__ or 592--ESM-I-60A-__
11 Current 10…100 A 193-ESM-I-100A-__ or 592--ESM-I-100A-__
12 Current 20…200 A 193-ESM-I-200A-__ or 592--ESM-I-200A-__
Code Description Communication Module Cat. No.
0Ignore —
1 EtherNet/IP with Dual Port Switch supporting DLR 193-ECM-ETR
2 DeviceNet 193-ECM-DNT
