Rockwell Automation Publication 193-UM015E-EN-P - October 2015 535
Metering and Diagnostics Chapter 8
Analog Module 2
Analog Module 2 – Input Channel 00
Analog Module 2 – Input Channel 00 (Parameter 114) reports the monitored
value of Analog Module 2 – Input Channel 00.
Table 529 - Analog Module 2 – Input Channel 00 (Parameter 114)
Analog Module 2 – Input Channel 01
Analog Module 2 – Input Channel 01 (Parameter 115) reports the monitored
value of Analog Module 2 – Input Channel 01.
Table 530 - Analog Module 2 – Input Channel 01 (Parameter 115)
Analog Module 2 – Input Channel 02)
Analog Module 2 – Input Channel 02 (Parameter 113) reports the monitored
value of Analog Module 2 – Input Channel 02.
Table 531 - Analog Module 2 – Input Channel 02 (Parameter 116)
Analog Module 2 Status
Analog Module 2 Status (Parameter 124) reports the status of Analog Module 2.
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
