510 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 8 Metering and Diagnostics
Table 465 - Current Imbalance (Parameter 52)
Voltage Monitor
The E300 relay’s voltage monitor diagnostics provides information on the voltage
being supplied to the load. The voltage diagnostics include three-phase voltage,
phase imbalance, phase rotation, and frequency.
L1-L2 Voltage
L1-L2 Voltage (Parameter 53) reports the voltage in volts in reference to the T1
and T2 power terminals of the E300 relay Sensing Module.
Table 466 - L1-L2 Voltage (Parameter 53)
L2-L3 Voltage
L2-L3 Voltage (Parameter 54) reports the voltage in volts in reference to the T2
and T3 power terminals of the E300 relay Sensing Module.
Table 467 - L2-L3 Voltage (Parameter 54)
Default Value 0
Minimum Value 0
Maximum Value 200
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 1
Units %
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
