Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 481
Commands Chapter 7
Clear Command
Clear Command (Parameter 165) allows you to clear historical logs, operating
statistics, and energy data within the nonvolatile memory of the E300 relay.
426 DemandPeriod 15 Min 547 InAMod4C1WarnLvl 0
427 NumberOfPeriods 1 548 InAnMod4Ch02Type Disable
549 InAMod4Ch2Format Eng Units
550 InAMod4C2TmpUnit Degrees C
551 InAMod4C2FiltFrq 17 Hz
552 InAMod4C2OpCktSt Upscale
553 InAnMod4Ch2RTDEn 3-Wire
554 InAMod4C2TripDly 1.0 Seconds
555 InAMod4C2TripLvl 0
556 InAMod4C2WarnLvl 0
557 OutAnMod4Type Disable
558 OutAnMod4Select Ave %FLA
559 OutAnMod4FltActn Zero
560 OutAnMod4dlActn Zero
561 FnlFltValStDur Zero
562 OutPt00FnlFltVal Open
563 OutPt01FnlFltVal Open
564 OutPt02FnlFltVal Open
565 OutDig1FnlFltVal Open
566 OutDig2FnlFltVal Open
567 OutDig3FnlFltVal Open
568 OutDig4FnlFltVal Open
569 NetStrtComFltAct Goto Value
570 NetStrtComFltVal Open
571 NetStrtComIdlAct Goto Value
572 NetStrtComIdlVal Open
573 NetStrtFnlFltVal Open
574 VoltageScale Volts
No. Parameter Name Default
Value
Units No. Parameter Name Default
Value
Units No. Parameter Name Default
Value
Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
