480 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 7 Commands
253 JamTripLevel 250 %FLA 382 OWInhibitTime 10 Seconds 503 InAMod3C0OpCktSt Upscale
254 JamWarningLevel 150 %FLA 383 OWTripDelay 1.0 Seconds 504 InAnMod3Ch0RTDEn 3-Wire
255 ULInhibitTime 10 Seconds 384 OWTripLevel 0.000 kW 505 InAMod3C0TripDly 1.0 Seconds
256 ULTripDelay 5.0 Seconds 385 OWWarningLevel 0.000 kW 506 InAMod3C0TripLvl 0
257 ULTripLevel 50 %FLA 386 UVARCInhibitTime 10 Seconds 507 InAMod3C0WarnLvl 0
258 ULWarningLevel 70 %FLA 387 UVARCTripDelay 1.0 Seconds 508 InAnMod3Ch01Type Disable
259 CIInhibitTime 10 Seconds 388 UVARCTripLevel 0.000 kVAR 509 InAMod3Ch1Format Eng Units
260 CITripDelay 5.0 Seconds 389 UVARCWarnLevel 0.000 kVAR 510 InAMod3C1TmpUnit Degrees C
261 CITripLevel 35 % 390 OVARCInhibitTime 10 Seconds 511 InAMod3C1FiltFrq 17 Hz
262 CIWarningLevel 20 % 391 OVARCTripDelay 1.0 Seconds 512 InAMod3C1OpCktSt Upscale
263 CTPrimary 5 392 OVARCTripLevel 0.000 kVAR 513 InAnMod3Ch1RTDEn 3-Wire
264 CTSecondary 5 393 OVARCWarnLevel 0.000 kVAR 514 InAMod3C1TripDly 1.0 Seconds
265 UCInhibitTime 10 Seconds 394 UVARGInhibitTime 10 Seconds 515 InAMod3C1TripLvl 0
266 L1UCTripDelay 1.0 Seconds 395 UVARGTripDelay 1.0 Seconds 516 InAMod3C1WarnLvl 0
267 L1UCTripLevel 35 % 396 UVARGTripLevel 0.000 kVAR 517 InAnMod3Ch02Type Disable
268 L1UCWarningLevel 40 % 397 UVARGWarnLevel 0.000 kVAR 518 InAMod3Ch2Format Eng Units
269 L2UCTripDelay 1.0 Seconds 398 OVARGInhibitTime 10 Seconds 519 InAMod3C2TmpUnit Degrees C
270 L2UCTripLevel 35 % 399 OVARGTripDelay 1.0 Seconds 520 InAMod3C2FiltFrq 17 Hz
271 L2UCWarningLevel 40 % 400 OVARGTripLevel 0.000 kVAR 521 InAMod3C2OpCktSt Upscale
272 L3UCTripDelay 1.0 Seconds 401 OVARGWarnLevel 0.000 kVAR 522 InAnMod3Ch2RTDEn 3-Wire
273 L3UCTripLevel 35 % 402 UVAInhibitTime 10 Seconds 523 InAMod3C2TripDly 1.0 Seconds
274 L3UCWarningLevel 40 % 403 UVATripDelay 1.0 Seconds 524 InAMod3C2TripLvl 0
275 OCInhibitTime 10 Seconds 404 UVATripLevel 0.000 kVA 525 InAMod3C2WarnLvl 0
276 L1OCTripDelay 1.0 Seconds 405 UVAWarningLevel 0.000 kVA 526 OutAnMod3Type Disable
277 L1OCTripLevel 100 % 406 OVAInhibitTime 10 Seconds 527 OutAnMod3Select Ave %FLA
278 L1OCWarningLevel 90 % 407 OVATripDelay 1.0 Seconds 528 OutAnMod3FltActn Zero
279 L2OCTripDelay 1.0 Seconds 408 OVATripLevel 0.000 kVA 529 OutAnMod3dlActn Zero
280 L2OCTripLevel 100 % 409 OVAWarningLevel 0.000 kVA 530 InAnMod4Ch00Type Disable
281 L2OCWarningLevel 90 % 410 UPFLagInhibTime 10 Seconds 531 InAMod4Ch0Format Eng Units
282 L3OCTripDelay 1.0 Seconds 411 UPFLagTripDelay 1.0 Seconds 532 InAMod3C0TmpUnit Degrees C
283 L3OCTripLevel 100 % 412 UPFLagTripLevel -90 % 533 InAMod4C0FiltFrq 17 Hz
284 L3OCWarningLevel 90 % 413 UPFLagWarnLevel -95 % 534 InAMod4C0OpCktSt Upscale
285 LineLossInhTime 10 Seconds 414 OPFLagInhibTime 10 Seconds 535 InAnMod4Ch0RTDEn 3-Wire
286 L1LossTripDelay 1.0 Seconds 415 OPFLagTripDelay 1.0 Seconds 536 InAMod4C0TripDly 1.0 Seconds
287 L2LossTripDelay 1.0 Seconds 416 OPFLagTripLevel -95 % 537 InAMod4C0TripLvl 0
288 L3LossTripDelay 1.0 Seconds 417 OPFLagWarnLevel -90 % 538 InAMod4C0WarnLvl 0
291 Datalink0 0 418 UPFLeadInhibTime 10 Seconds 539 InAnMod4Ch01Type Disable
292 Datalink1 0 419 UPFLeadTripDelay 1.0 Seconds 540 InAMod4Ch1Format Eng Units
293 Datalink2 0 420 UPFLeadTripLevel 90 % 541 InAMod4C1TmpUnit Degrees C
294 Datalink3 0 421 UPFLeadWarnLevel 95 % 542 InAMod4C1FiltFrq 17 Hz
295 Datalink4 0 422 OPFLeadInhibTime 10 Seconds 543 InAMod4C1OpCktSt Upscale
296 Datalink5 0 423 OPFLeadTripDelay 1.0 Seconds 544 InAnMod4Ch1RTDEn 3-Wire
297 Datalink6 0 424 OPFLeadTripLevel 95 % 545 InAMod4C1TripDly 1.0 Seconds
298 Datalink7 0 425 OPFLeadWarnLevel 90 % 546 InAMod4C1TripLvl 0
No. Parameter Name Default
Value
Units No. Parameter Name Default
Value
Units No. Parameter Name Default
Value
Units
