Allen-Bradley E300 User Manual

712 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Appendix D EtherNet/IP Information
Electrical Energy Object — CLASS CODE 0x004F
No class attributes are supported for the Electrical Energy Object.
A single instance of the Electrical Energy Object is supported
Table 642 - Electrical Energy Object Instance Attributes
11 REAL Energy Transfer Rate User Setting 0.0
12
STRUCT of UINT,
Padded EPATH
1
Energy Type Specific Object Path Attribute 12 value
13 UINT
Energy Aggregation Path Array
Size
0
14
Array of STRUCT
of UINT, Padded
EPATH
1
Energy Aggregation Paths Null
15 STRINGI Energy Identifier
LanguageChar1 USINT =‘e’
LanguageChar2 USINT)=‘n’
LanguageChar3 USINT) =‘g’
CharStringStruct USINT=0xD0
CharSet UINT = 0 = undefined
InternationalString = null
16 BOOL Odometer Reset Enable Attribute 16 value
17 BOOL Metering State 1
Attribute ID Access Rule Name Data Type Value
1Get
Real Energy Consumed
Odometer
ODOMETER Returns params 80-84 values.
3Get
Real Energy Net
Odometer
SIGNED ODOMEETER Returns params 80-84 values.
4Get
Reactive Energy
Consumed Odometer
ODOMETER Returns params 85-89 values.
5Get
Reactive Energy
Generated Odometer
ODOMETER Returns params 90-94 values.
6Get
Reactive Energy Net
Odometer
SIGNED ODOMETER Returns params 95-99 values.
7Get
Apparent Energy
Odometer
ODOMETER Returns params 100-104 values.
9 Get Line Frequency REAL Param 62 value converted to a REAL
10 Get L1 Current REAL Param 43 value converted to a REAL
11 Get L2 Current REAL Param 44 value converted to a REAL
12 Get L3 Current REAL Param 45 value converted to a REAL
13 Get Average Current REAL Param 46 value converted to a REAL
14 Get
Percent Current
Unbalance
REAL Param 52 value converted to a REAL
15 Get L1 to N Voltage REAL Param 57 value converted to a REAL
16 Get L2 to N Voltage REAL Param 58 value converted to a REAL
17 Get L3 to N Voltage REAL Param 59 value converted to a REAL
18 Get Avg Voltage L to N REAL Param 60 value converted to a REAL
19 Get L1 to L2 Voltage REAL Param 53 value converted to a REAL
20 Get L2 to L3 Voltage REAL Param 54 value converted to a REAL
21 Get L3 to L1 Voltage REAL Param 55 value converted to a REAL
22 Get Avg Voltage Lto N REAL Param 56 value converted to a REAL
Attribute ID Data Type Name Value

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
