Rockwell Automation Publication 193-UM015E-EN-P - October 2015 711
EtherNet/IP Information Appendix D
Table 638 - Base Energy Object Class Attributes
A single instance of the Base Energy Object is supported
Table 639 - Base Energy Instance Attributes
The following services are implemented for the Base Energy Object.
Table 640 - Base Energy Object Common Services
The following table describes the Get_Attributes_All response.
Table 641 - Base Energy Object Class Attributes Get_Attributes_All Response
Attribute ID Access Rule Name Data Type Value
1 Get Object Revision USINT 2
Attribute ID Access Rule Name Data Type Value
1 Get Energy/Resource Type UINT 1 = Electrical
2Get
Energy Object
Capabilities
WORD 0x0001 = Energy Measured
3 Get Energy Accuracy UINT
500 = 5.00 percent of full scale
reading
4GetEnergy Accuracy BasisUINT 1 = Percent of full scale reading
5Get
Full Scale Power
Reading
Real x.xxx kW (TBD)
7Get
Consumed Energy
Odometer
ODOMETER Returns params 80-84 values.
9 Get Total Energy Odometer SIGNED ODOMETER Returns params 80-84 values.
10 Get Total Real Power REAL Param 67 value converted to a REAL
12 Get
Energy Type Specific
Object Path
STRUCT of UINT
Padded EPATH
03 00 21 00 4F 00 24 01
16 Set Odometer Reset Enable BOOL
0 = Disabled (Default)
1 = Enabled
Enables resetting of Energy
Odometers by Reset service
Service Code
Implemented for:
Service Name
Class Instance
0x01 No Yes GetAttributes_All
0x05 No Yes Reset
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Data Type Name Value
1 UINT Energy/Resource Type Attribute 1 value
2 WORD Energy Object Capabilities Attribute 2 value
3 UINT Energy Accuracy Attribute 3 value
4 UINT Energy Accuracy Basis Attribute 4 value
5 REAL Full Scale Reading Attribute 5 value
6 UINT Data Status 0
7 ODOMETER Consumed Energy Odometer 0Attribute 7 value
8 ODOMETER Generated Energy Odometer 0,0,0,0,0
9
SIGNED
ODOMETER
Total Energy Odometer Attribute 9 value
10 REAL Energy Transfer Rate Attribute 10 value
