Rockwell Automation Publication 193-UM015E-EN-P - October 2015 611
Chapter 11
Firmware Updates
Introduction
This chapter provides detailed information about firmware compatibility among
the various E300™ Electronic Overload Relay modules and provides instructions
on how to update firmware for an E300 relay module.
Firmware Compatibility
The sensing, control, and communication modules of an E300 relay have their
own firmware for the functionality of the module and its subsystems. You can
update each module and its associated subsystems by using the ControlFLASH
utility, which is the same utility that is used to download firmware into a Logix-
based controller. The ControlFLASH kits for E300 firmware system revisions
v1.085, v2.085, v3.083, v4.083, and v5.082 use one command to update all of the
E300 relay modules and subsystems for that specific system release.
Table 567
shows the specific firmware revisions for all E300 relay modules and
subsystems for all of the available system releases.
Table 567 - E300 System Revision Table
Table 568 shows which firmware revisions are compatible with the other E300
relay modules and their associated subsystems.
E300 System
Revision
1.034 1.035 1.085 2.034 2.035 2.036 2.085 3.033 3.034 3.049 3.050 3.083 4.033 4.034 4.049 4.050 4.083 5.082
E300 Control
Module
193-EIO
Application
1.002 1.004 1.005 2.002 2.003 2.004 2.005 3.001 3.002 3.001 3.002 3.003 4.001 4.002 4.001 4.002 4.003 5.002
193-EIO Boot
Code
1.005 1.005 1.005 1.006 1.006 1.006 1.006 1.007 1.007 1.007 1.007 1.007 1.007 1.007 1.007 1.007 1.008 1.008
193-EIO EDS
Files
———————3.0013.0013.0013.0013.0014.0014.0014.0014.0014.0015.001
193-DLX
Program Files
—————————————————1.001
193-EIO
Language
Files
—————————————————1.001
E300
Communication
Module
193-ECM-ETR
Application
1.003 1.003 1.006 1.003 1.003 1.003 1.006 1.003 1.003 1.004 1.004 1.006 1.003 1.003 1.004 1.004 1.006 1.006
193-ECM-ETR
Boot Code
2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001 2.001
193-ECM-ETR
FPGA
1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008 1.008
193-ECM-ETR
File System
1.001 1.001 1.002 1.001 1.001 1.001 1.002 1.001 1.001 1.002 1.002 1.002 1.001 1.001 1.002 1.002 1.002 1.002
E300 Sensing
Module
193-ESM
Sensing
Module
1.001 1.001 1.001 2.002 2.002 2.003 2.003 2.002 2.003 2.002 2.003 2.003 2.002 2.003 2.002 2.003 2.003 2.003
