Total Power Factor = (L1 Power Factor + L2 Power Factor + L3 Power Factor) / 3
When Single or Three Phase (Parameter 176) is set to Single Phase, Total Power
Factor is calculated as follows:
Total Power Factor = (L1 Power Factor + L2 Power Factor) / 2
Table 493 - Total Power Factor (Parameter 79)
Energy Monitor
The E300 relay’s energy monitor diagnostics provides information on the
electrical energy the load is consuming. The energy diagnostics include kWh,
kVARh, kVAh, kW Demand, kVAR Demand, and kVA Demand.
kWh 10
9
kWh 10
9
(Parameter 80) reports a component of total real energy (kWh).
Multiply this value by 10
9
and add to the other kWh parameters.
Represents XXX,000,000,000.000 kW h
Table 494 - kWh x 10E9 (Parameter 80)
kWh 10
6
kWh 10
6
(Parameter 81) reports a component of total real energy (kWh).
Multiply this value by 10
6
and add to the other kWh parameters.
Represents000,XXX,000,000.000 kWh
Default Value 0.0
Minimum Value -100.0
Maximum Value 100.0
Parameter Type INT
Size (Bytes) 2
Scaling Factor 10
Units %
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
