Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 497
Metering and Diagnostics Chapter 8
Device Status 0
Device Status 0 (Parameter 20) reports the general status of the E300 relay and
the sensing capabilities that are present.
Table 435 - Device Status 0 (Parameter 20)
Device Status 0 bit 14, "Ready", is cleared under the following circumstances:
• Device Status 0 bit 0, "Trip Present", is set
• The E300 relay has not completed its power-up initialization
• The processing of data in a configuration assembly is in progress
• A CopyCat function is in progress
• A Fact
ory Defaults command has been invoked and is in progress.
Bit
1514131211109876543210 Function
X Trip Present
X Warning Present
X Invalid Configuration
X Current Present
X Ground Fault Current Present
X Voltage Present
X Emergency Start Enabled
X DeviceLogix Enabled
X Feedback Timeout Enabled
X Operator Station Present
X Voltage Sensing Present
X Internal Ground Fault Sensing Present
X External Ground Fault Sensing Present
XPTC Sensing Present
XReady
Reserved

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
