42 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 2 Installation and Wiring
Figure 25 - E300 Sensing Module 592-ESM-___-__-S4 with NEMA Contactor Size 4
DIN Rail / Panel Mount
Dimensions
Approximate dimensions are shown in millimeters (inches). Dimensions are not
intended to be used for manufacturing purposes.
Figure 26 - E300 Sensing Module 193-ESM-___-30A-T and 193-ESM-___-60A-T
187.5
(7.38)
414
(16.30)
11.4
(0.45)
312.7
(12.31)
25.2
(0.99)
250
(9.84)
160.2
(6.31)
130.1
(5.12)
n 8.7
(0.34)
5 PLCS
189.9
(7.48)
161.7
(6.37)
135
(5.32)
with mtg. feet
4.5
(0.18)
125
(4.921)
5
(0.197)
n 4.8 (0.189)
116.2
(4.58)
w/o mtg. feet
39
(1.03)
11.35
(0.45)
30.1
(1.19)
45
(1.76)
124
(4.88)
shown with panel mount feet accessory
q
Mount feet accessory Cat. No.: 140M-C-N45
