Allen-Bradley E300 User Manual

538 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 8 Metering and Diagnostics
Analog Module 4
Analog Module 4 – Input Channel 00
Analog Module 4 – Input Channel 00 (Parameter 120) reports the monitored
value of Analog Module 4 – Input Channel 00.
Table 537 - Analog Module 4 – Input Channel 00 (Parameter 120)
Analog Module 4 – Input Channel 01
Analog Module 4 – Input Channel 01 (Parameter 121) reports the monitored
value of Analog Module 4 – Input Channel 01.
Table 538 - Analog Module 4 – Input Channel 01 (Parameter 121)
Analog Module 4 – Input Channel 02
Analog Module 4 – Input Channel 02 (Parameter 122) reports the monitored
value of Analog Module 4 – Input Channel 02.
Table 539 - Analog Module 4 – Input Channel 02 (Parameter 122)
Analog Module 4 Status
Analog Module 4 Status (Parameter 126) reports the status of Analog Module 4.
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
