428 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 6 Protective Trip and Warning Functions
Thermistor (PTC) Protection
The following E300 relay control modules can accept up to 6 thermistors (PTC)
temperature sensors wired in series to monitor the temperature of a motor’s
windings, rotor, and/or bearings.
193-EIOGP-42-24D
193-EIOGP-22-120
193-EIOGP-22-240
The
thermistor (PTC) based temperature sensors connect to the IT1 and IT2
term
inals of the E300 Control Module.
Thermistor (PTC) Trip
The E300 relay trips with a thermistor (PTC) trip indication if:
No trip currently exists
Resistance of the thermistor (PTC) sensors is greater than 3400
If
the E300 relay trips on a thermistor (PTC), the following occurs:
The TRIP/WARN LED flashes a red 3-long / 2-short blink pattern
Bit 1 in
Control Trip Status (Parameter 7) sets to 1
Bit 0 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Trip Relay opens
Any relay outputs configured as a Control Relay opens
IMPORTANT
The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
Output PT00 Protection Fault Action (Parameter 304)
Output PT00 Protection Fault Value (Parameter 305)
Output PT01 Protection Fault Action (Parameter 310)
Output PT01 Protection Fault Value (Parameter 311)
Output PT02 Protection Fault Action (Parameter 316)
Output PT02 Protection Fault Value (Parameter 317)
Output Digital Module 1 Protection Fault Action (Parameter 322)
Output Digital Module 1 Protection Fault Value (Parameter 323)
Output Digital Module 2 Protection Fault Action (Parameter 328)
Output Digital Module 2 Protection Fault Value (Parameter 329)
Output Digital Module 3 Protection Fault Action (Parameter 334)
Output Digital Module 3 Protection Fault Value (Parameter 335)
Output Digital Module 4 Protection Fault Action (Parameter 340)
Output Digital Module 4 Protection Fault Value (Parameter 342)
