Allen-Bradley E300 User Manual

82 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 4 System Operation and Configuration
Enable Option Match Protection Warning (Parameter 192)
To enable the Option Match feature to cause a warning in the event of an option
mismatch, place a (1) in bit position 8 of Parameter 192 (Control Warning
Enable). You can select the specific option match features to cause a warning in
Parameter 233 (Option Match Action).
Table 31 - Enable Option Match Protection Warning Bit Function Detail— Control Warning
Enable (Parameter 192)
Control Module Type (Parameter 221)
The E300 relay offers six different control modules. Place the value of the
expected control module into Parameter 221. A value of (0) disables the Option
Match feature for the control module.
Table 32 - Control Module Type (Parameter 221)
Bit
1514131211109876543210 Function
Reserved
Reserved
X DeviceLogix Warning Enable
Reserved
Reserved
Reserved
Reserved
Reserved
X Option Match Warning Enable
X Feedback Timeout Warning Enable
X Expansion Bus Warning Enable
X Number Of Starts Warning Enable
X Operating Hours Warning Enable
Reserved
Code Description Control Module Cat. No.
0Ignore —
1 6 Inputs, 24V DC / 3 Relay Outputs 193-EIO-63-24D
2 4 Inputs, 110-120V AC 50/60Hz / 3 Relay Outputs 193-EIO-43-120
3 4 Inputs, 220-240V AC 50/60Hz / 3 Relay Outputs 193-EIO-43-240
4 4 Inputs, 24V DC / 2 Relay Outputs / External Ground Fault / PTC 193-EIOGP-42-24D
5 2 Inputs, 110-120V AC 50/60Hz / 2 Relay Outputs / External Ground Fault / PTC 193-EIOGP-22-120
6 2 Inputs, 220-240V AC 50/60Hz / 2 Relay Outputs / External Ground Fault / PTC 193-EIOGP-22-240

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
