608 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 10 EtherNet/IP Communication
Text Notifications
The E300 relay EtherNet/IP Communication Module can send a text message to
a wireless phone by e-mailing the wireless phone's service provider. The format
for the text message is provided by the service provider and looks similar to the
example formats below.
• AT&T™: 10-digit wireless phone number@txt.att.net
• Sprint®: 10-digit wireless phone number@messaging.sprint.pcs.com
Limitations
Based on the functionality of the E300 relay EtherNet/IP Communication
Module, there are some limitations on when the e-mails can be triggered.
• If two events occur at the same time, an e-mail is only sent for the most
signific
ant error.
• I
f the device has been configured to send an e-mail for a lower prioritized
eve
nt and this event occurs at the same time as a higher prioritized event
for which the device has not been programmed to send an e-mail, an e-mail
is not sent for either event.
• Th
e Clear e-mail is only sent when all events have been cleared and an
eve
nt e-mail has previously been sent.
Troubleshooting
The following table identifies possible causes and corrective actions when
troubleshooting the E300 relay EtherNet/IP Communication Module.
Status LED Color State Possible Cause Corrective Action
Network Status (NS)
None —
The E300 EtherNet/IP Communication Module is not
receiving power.
Verify that the proper control voltage exists between
terminals A1 and A2 on the E300 Control Module.
Green, Red,
Not Illuminated
Flashing (once)
Normal This is a normal power-up sequence.
Green Flashing
The E300 EtherNet/IP Communication Module is online,
but with no connections established.
Check the EtherNet/IP master and its scan list for correct
scanner configuration.
Green Solid
Normal operating state and the E300 EtherNet/IP
Communication Module is allocated to a master.
No action is required.
Red Flashing One or more EtherNet/IP connections timed out. Reset the EtherNet/IP master device.
Red Solid
Diagnostics test failed on power-up/reset. An internal
fault exists.
Cycle power to the unit. If the fault still exists, replace
the unit.
Duplicate EtherNet/IP module address exists. Two
modules cannot have the same address.
Change the IP address to a valid setting and reset the
device.
A fatal communication error occurred. Check Ethernet media for proper installation.
