Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 537
Metering and Diagnostics Chapter 8
Table 534 - Analog Module 3 – Input Channel 01 (Parameter 118)
Analog Module 3 – Input Channel 02
Analog Module 3 – Input Channel 02 (Parameter 119) reports the monitored
value of Analog Module 3 – Input Channel 02.
Table 535 - Analog Module 3 – Input Channel 02 (Parameter 119)
Analog Module 3 Status
Analog Module 3 Status (Parameter 125) reports the status of Analog Module 3.
Table 536 - Analog Module 3 Status (Parameter 125)
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
Default Value 0
Minimum Value -32768
Maximum Value 32767
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units 
Bit
Function
1514131211109876543210
XInput Channel 00 Open Circuit
XInput Channel 00 Over Range
XInput Channel 00 Under Range
XInput Channel 01 Open Circuit
XInput Channel 01 Over Range
XInput Channel 01 Under Range
XInput Channel 02 Open Circuit
XInput Channel 02 Over Range
XInput Channel 02 Under Range
XOutput Channel 00 Open Circuit
XOutput Channel 00 Hold Last State Mode Active
XOutput Channel 00 Over Range
XOutput Channel 00 Under Range
XAnalog Module Configured
XAnalog Module Warning (Module Number Dial Changed)
XAnalog Module Faulted
