Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 479
Commands Chapter 7
195 SetOperatingMode Net
Overload
331 OutDig2ComFltVal Open 455 InAnMod1Ch02Type Disable
196 InPt00Assignment Normal 332 OutDig2ComIdlAct Goto Value 456 InAMod1Ch2Format Eng Units
197 InPt01Assignment Normal 333 OutDig2ComIdlVal Open 457 InAMod1C2TmpUnit Degrees C
198 InPt02Assignment Normal 334 OutDig3PrFltAct Goto Value 458 InAMod1C2FiltFrq 17 Hz
199 InPt03Assignment Normal 335 OutDig3PrFltVal Open 459 InAMod1C2OpCktSt Upscale
200 InPt04Assignment Normal 336 OutDig3ComFltAct Goto Value 460 InAnMod1Ch2RTDEn 3-Wire
201 InPt05Assignment Normal 337 OutDig3ComFltVal Open 461 InAMod1C2TripDly 1.0 Seconds
202 OutPt0Assignment * Trip Relay 338 OuDig3ComIdlAct Goto Value 462 InAMod1C2TripLvl 0
203 OutPt1Assignment Normal 339 OutDig3ComIdlVal Open 463 InAMod1C2WarnLvl 0
204 OutPt2Assignment Normal 340 OutDig4PrFltAct Goto Value 464 OutAnMod1Type Disable
205 StartsPerHour 2 341 OutDig4PrFltVal Open 465 OutAnMod1Select Ave %FLA
206 StartsInterval 600 Seconds 342 OutDig4ComFltAct Goto Value 466 OutAnMod1FltActn Zero
207 PMTotalStarts 0 343 OutDig4ComFltVal Open 467 OutAnMod1IdlActn Zero
208 PMOperatingHours 0 Hrs 344 OutDig4ComIdlAct Goto Value 468 InAnMod2Ch00Type Disable
209 ActFLA2wOutput Disable 345 OutDig4ComIdlVal Open 469 InAMod2Ch0Format Eng Units
211 SecurityPolicy 0x801F 346 CommOverride Disable 470 InAMod2C0TmpUnit Degrees C
212 Language English 347 NetworkOverride Disable 471 InAMod2C0FiltFrq 17 Hz
213 FeedbackTimeout 500 350 PtDevOutCOSMask 0x0000 472 InAMod2C0OpCktSt Upscale
214 TransitionDelay 10000 352 VoltageMode Delta 473 InAnMod2Ch0RTDEn 3-Wire
215 InterlockDelay 100 353 PTPrimary 480 474 InAMod2C0TripDly 1.0 Seconds
216 EmergencyStartEn Disable 354 PTSecondary 480 475 InAMod2C0TripLvl 0
221 ControlModuleTyp Ignore 355 UVInhibitTime 10 Seconds 476 InAMod2C0WarnLvl 0
222 SensingModuleTyp Ignore 356 UVTripDelay 1.0 Seconds 477 InAnMod2Ch01Type Disable
223 CommsModuleType Ignore 357 UVTripLevel 100.0 Volt 478 InAMod2Ch1Format Eng Units
224 OperStationType Ignore 358 UVWarningLevel 400.0 Volt 479 InAMod2C1TmpUnit Degrees C
225 DigitalMod1Type Ignore 359 OVInhibitTime 10 Seconds 480 InAMod2C1FiltFrq 17 Hz
226 DigitalMod2Type Ignore 360 OVTripDelay 1.0 Seconds 481 InAMod2C1OpCktSt Upscale
227 DigitalMod3Type Ignore 361 OVTripLevel 500.0 Volt 482 InAnMod2Ch1RTDEn 3-Wire
228 DigitalMod4Type Ignore 362 OVWarningLevel 490.0 Volt 483 InAMod2C1TripDly 1.0 Seconds
229 AnalogMod1Type Ignore 363 PhRotInhibitTime 10 Seconds 484 InAMod2C1TripLvl 0
230 AnalogMod2Type Ignore 364 PhaseRotTripType ABC 485 InAMod2C1WarnLvl 0
231 AnalogMod3Type Ignore 365 VIBInhibitTime 10 Seconds 486 InAnMod2Ch02Type Disable
232 AnalogMod4Type Ignore 366 VIBTripDelay 1.0 Seconds 487 InAMod2Ch2Format Eng Units
233 MismatchAction 0x0000 367 VIBTripLevel 15 % 488 InAMod2C2TmpUnit Degrees C
239 PLInhibitTime 0 Seconds 368 VIBWarningLevel 10 % 489 InAMod2C2FiltFrq 17 Hz
240 PLTripDelay 1 Seconds 369 UFInhibitTime 10 Seconds 490 InAMod2C2OpCktSt Upscale
241 GroundFaultType Internal 370 UFTripDelay 1.0 Seconds 491 InAnMod2Ch2RTDEn 3-Wire
242 GFInhibitTime 10 Seconds 371 UFTripLevel 57 Hz 492 InAMod2C2TripDly 1.0 Seconds
243 GFTripDelay 0.5 Seconds 372 UFWarningLevel 58 Hz 493 InAMod2C2TripLvl 0
244 GFTripLevel 2.50 Amps 373 OFInhibitTime 10 Seconds 494 InAMod2C2WarnLvl 0
245 GFWarningDelay 0 Seconds 374 OFTripDelay 1.0 Seconds 495 OutAnMod2Type Disable
246 GFWarningLevel 2.00 Amps 375 OFTripLevel 63 Hz 496 OutAnMod2Select Ave %FLA
247 GFFilter Disable 376 OFWarningLevel 62 Hz 497 OutAnMod2FltActn Zero
248 GFMaxInhibit Disable 377 PowerScale kW 498 OutAnMod2dlActn Zero
249 StallEnabledTime 10 Seconds 378 UWInhibitTime 10 Seconds 499 InAnMod3Ch00Type Disable
250 StallTripLevel 600 %FLA 379 UWTripDelay 1.0 Seconds 500 InAMod3Ch0Format Eng Units
251 JamInhibitTime 10 Seconds 380 UWTripLevel 0.000 kW 501 InAMod3C0TmpUnit Degrees C
252 JamTripDelay 5.0 Seconds 381 UWWarningLevel 0.000 kW 502 InAMod3C0FiltFrq 17 Hz
No. Parameter Name Default
Value
Units No. Parameter Name Default
Value
Units No. Parameter Name Default
Value
Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
