Rockwell Automation Publication 193-UM015E-EN-P - October 2015 125
System Operation and Configuration Chapter 4
Table 135 - Analog Module 1 – Input Channel 00 RTD Type Enable (Parameter 442)
Analog Module 1 – Input Channel 01 Type
Analog Module 1 – Input Channel 01 Type (Parameter 446) defines the type of
analog signal that Input Channel 01 of Analog Module 1 monitors.
Table 136 - Analog Module 1 – Input Channel 01 Type (Parameter 446)
Analog Module 1 – Input Channel 01 Format
Analog Module 1 – Input Channel 01 Format (Parameter 447) defines the data
format for how the analog reading is reported.
Table 137 - Analog Module 1 – Input Channel 01 Format (Parameter 447)
Value Assignment Description
0 3-Wire Scan a 3-wire RTD sensor
1 2-Wire Scan a 2-wire RTD sensor
Value Assignment Description
0 Disabled Disable the analog input
1 4To20mA Read an analog current signal from 4…20 mA
2 0To20mA Read an analog current signal from 0…20 mA
3 0To10Volts Read an analog voltage signal from 0…10 V DC
4 1To5Volts Read an analog voltage signal from 1…5 V DC
5 0To5Volts Read an analog voltage signal from 0…5 V DC
6 100Pt385 Read a 100 Ω Pt 385 RTD Sensor
7 200Pt385 Read a 200 Ω Pt 385 RTD Sensor
8 500Pt385 Read a 500 Ω Pt 385 RTD Sensor
9 1000Pt385 Read a 1000 Ω Pt 385 RTD Sensor
10 100Pt3916 Read a 100 Ω Pt 3916 RTD Sensor
11 200Pt3916 Read a 200 Ω Pt 3916 RTD Sensor
12 500Pt3916 Read a 500 Ω Pt 3916 RTD Sensor
13 1000Pt3916 Read a 1000 Ω Pt 3916 RTD Sensor
14 10Cu426 Read a 10 Ω Cu 426 RTD Sensor
15 100Ni618 Read a 100 Ω Ni 618 RTD Sensor
16 120Ni672 Read a 120 Ω Ni 672 RTD Sensor
17 604NiFe518 Read a 604 Ω NiFe 518 RTD Sensor
18 150ohm Read a resistance signal from 0…150 Ω
19 750ohm Read a resistance signal from 0…750 Ω
20 3000ohm Read a resistance signal from 0…3000 Ω
21 6000ohm
Read a resistance signal from 0…6000 Ω. This
setting can be used with PTC and NTC sensors.
Value Assignment Description
0 EngUnits Engineering Units (mA, V, °C, °F, or Ω)
1 EngUnitsTimes10 Engineering Units x 10 (mA, V, °C, °F, or Ω)
2 RawProportional Raw / Proportional (-32768…+32767)
3 ScaledForPID Scaled for PID (0…16383)
