Protective Trip and Warning Functions Chapter 6
Table 287 - Voltage Trip Enabled (Parameter 184)
Table 288 - Voltage Warning Enable (Parameter 190)
Voltage Trip Status (Parameter 5) and Voltage Warning Status (Parameter 11) are
used to view the status of the respective voltage-based protective trip and warning
functions.
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X
Under Voltage Trip
X
Over Voltage Trip
X
Voltage Imbalance Trip
X
Phase Rotation Mismatch Trip
X
Under Frequency Trip
X
Over Frequency Trip
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
X
Under Voltage Warning
X
Over Voltage Warning
X
Voltage Imbalance Warning
X
Phase Rotation Mismatch Warning
X
Under Frequency Warning
X
Over Frequency Warning
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
