366 Rockwell Automation Publication 193-UM015E-EN-P - October 2015

Chapter 6 Protective Trip and Warning Functions

Table 289 - Voltage Trip Status (Parameter 5)

Table 290 - Voltage Warning Status (Parameter 11)

Bit

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function

Under Voltage Trip

Over Voltage Trip

Voltage Imbalance Trip

Phase Rotation Mismatch Trip

Under Frequency Trip

Over Frequency Trip

Reserved

Bit

1514131211109876543210 Function

Under Voltage Warning

Over Voltage Warning

Voltage Imbalance Warning

Phase Rotation Mismatch Warning

Under Frequency Warning

Over Frequency Warning

Reserved
