Allen-Bradley E300 - Page 208

208 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 5 Operating Modes
Figure 113 - Reversing Starter (Network) DeviceLogix Program, Part B
Timing Diagram
Figure 114 - Reversing Starter (Network) Timing Diagram
Trip Event
REV (Relay 1)
FWD (Relay 0)
Trip Status
Trip Reset
Forward
Reverse
