234 Rockwell Automation Publication 193-UM015E-EN-P - October 2015

Chapter 5 Operating Modes

Figure 139 - Reversing Starter (Local I/O) – Two-wire Control with Feedback DeviceLogix

Program, Part C

Timing Diagram

Figure 140 - Reversing Starter (Operator Station) with Feedback Timing Diagram

Trip Event Feedback

Timeout

Forward

Stop

REV (Relay 1)

FWD (Relay 0)

Timer

Feedback

Timeout Trip

Trip Status

Trip Reset

Reverse

FWD Feedback

REV Feedback
