Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 329
Protective Trip and Warning Functions Chapter 6
Stall Enabled Time
Stall Enabled Time (Parameter 249) allows you to adjust the time the E300 relay
monitors for a stall condition during the motor starting sequence and is
adjustable from 0…250 s.
Table 248 - Stall Enabled Time (Parameter 249)
Stall Trip Level
Stall Trip Level (Parameter 250) allows you to define the locked rotor current
and is adjustable from 100…600% of the FLA Setting (Parameter 171).
Stall Enabled Time (Parameter 249)
Default Value 10
Minimum Value 0
Maximum Value 250
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units Seconds

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
