Allen-Bradley E300 User Manual

358 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 6 Protective Trip and Warning Functions
L1 Line Loss Trip
The E300 relay trips with a L1 Line Loss indication if:
• No trip currently exists
• L1 Over Current Trip is enabled
• L1 Line
Loss is activated via the appropriately programmed digital input
(see
Input Assignments, Parameters 196…201, in Chapter
4)
• Line Loss Inhibit Timer has expired
• L1 Percent FLA (Parameter 47) is
• equal to 0% for a time period greater than the L1 Line Loss Trip Delay.
If
the E300 relay trips on a L1 Line Loss, the:
• T
RIP/WARN LED status indicator flashes a red 14-short blink pattern
• Bit 13 in Current Trip Status (Parameter 4) sets to 1
• Bit 0 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Trip Relay open
• Any relay outputs configured as a Control Relay open
• Any relay outputs configured as a Trip Alarm close
• Any relay outputs configured as a Normal Relay are placed in their
P
rote
ction Fault state (if so programmed)
Minimum Value 0
Maximum Value 250
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units Seconds

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
