Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 379
Protective Trip and Warning Functions Chapter 6
Under Frequency Trip
The E300 relay trips with an Under Frequency indication if:
• No trip currently exists
• Under Frequency Trip is enabled
• Voltage is present
• Under Frequency Inhibit Time has expired
• The voltage frequency is less than the Under Frequency Trip Level for a
time
period greater than the Under Frequency Trip Delay.
If the E300 relay trips on an under frequency, the:
• TRIP/WARN LED status indicator flashes a red 1-long / 5-short blink
patter
n
• Bit 4 in Voltage Trip Status (Parameter 5) sets to 1
• Bit 0 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Trip Relay open
• Any relay outputs configured as a Control Relay open
• Any relay outputs configured as a Trip Alarm close
• Any relay outputs configured as a Normal Relay are placed in their
P
r
ote
ction Fault state (if so programmed)
Minimum Value 0
Maximum Value 250
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units Seconds

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
