Allen-Bradley E300 User Manual

394 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 6 Protective Trip and Warning Functions
Under kVAR Generated Inhibit Time
Under kVAR Generated Inhibit Time (Parameter 394) allows you to inhibit an
under power factor leading trip and warning from occurring during the motor
starting sequence. It is adjustable from 0…250 seconds.
Table 327 - Under kVAR Generated Inhibit Time (Parameter 394)
Over kVAR Generated Inhibit Time
Over kVAR Generated Inhibit Time (Parameter 398) allows you to inhibit an
over reactive power (kVAR) generated trip and warning from occurring during
the motor starting sequence. It is adjustable from 0…250 seconds.
Table 328 - Over kVAR Generated Inhibit Time (Parameter 398)
Under kVAR Consumed Trip
The E300 relay trips with an Under kVAR Consumed indication if:
• No trip currently exists
• Under kVAR Consumed Trip is enabled
• Current is present
• Voltage is present
• Under kVAR Consumed Inhibit Time has expired
• The total reactive power (kVAR) consumed is less than the Under kVAR
Con
su
med Trip Level for a time period greater than the Under kVAR
Consumed Trip Delay.
If the E300 relay trips on an under reactive power (kVAR) consumed, the:
• TRIP/WARN LED status indicator flashes a red 2-long / 3-short blink
patter
n
• B
it 2 in Power Trip Status (Parameter 6) sets to 1
Default Value 10
Minimum Value 0
Maximum Value 250
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units Seconds
Default Value 10
Minimum Value 0
Maximum Value 250
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units Seconds

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
