Allen-Bradley E300 User Manual

40 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 2 Installation and Wiring
Figure 22 - E300 Sensing Module 592-ESM-___-__-S2 with NEMA Contactor Size 0 and Size 1
Figure 23 - E300 Sensing Module 592-ESM-___-__-S2 with NEMA Contactor Size 2
180 (7.06)
157 (6.17)
249 (9.78)
35 (1.38)
70
(2.75)
12 (0.46)
n 6 (0.22)
90
(3.56)
125
(4.91)
219 (8.63)
184 (7.24)
276 (10.85)
n 6 (0.22)
100
(3.94)
40 (1.58)
80
(3.15)
125
(4.91)
12 (0.46)

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
