Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 403
Protective Trip and Warning Functions Chapter 6
Table 337 - Under kVAR Generated Warn Level (Parameter 397)
Over kVAR Generated Trip
The E300 relay trips with an Over kVAR Generated indication if:
• No trip currently exists
• Over kVAR Generated Trip is enabled
• Current is present
• Voltage is present
• Over kVAR Generated Inhibit Time has expired
• The total reactive power (kVAR) generated is greater than the Over
• kVAR Generated Trip Level for a time period greater than the Over kVAR
G
ene
rated Trip Delay.
If the E300 relay trips on an over reactive power (kVAR) generated, the:
• TRIP/WARN LED status indicator flashes a red 2-long / 6-short blink
patter
n
• Bit 5 in Power Trip Status (Parameter 6) sets to 1
• Bit 0 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Trip Relay open
• Any relay outputs configured as a Control Relay open
• Any relay outputs configured as a Trip Alarm close
• Any relay outputs configured as a Normal Relay are placed in their
P
r
ote
ction Fault state (if so programmed)
Default Value 0.000
Minimum Value 0.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kVAR
IMPORTANT
The Under kVAR Generated Warning function does not include a time delay
feature. Once the Under kVAR generated Inhibit Time has expired, the Under
kVAR Generated Warning indication is instantaneous.

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
