Page #430 background image
430 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 6 Protective Trip and Warning Functions
DeviceLogix Trip
The E300 relay trips with a DeviceLogix trip indication if:
No trip currently exists
The DeviceLogix program activates the DeviceLogix Trip bit
If
the E300 relay trips on a DeviceLogix program, the following occurs:
T
he TRIP/WARN LED flashes a red 3-long / 3-short blink pattern
Bit 2 in
Control Trip Status (Parameter 7) sets to 1
Bit 0 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Trip Relay opens
Any relay outputs configured as a Control Relay opens
Any relay outputs configured as a Trip Alarm closes
Any relay outputs configured as a Normal Relay are placed in their
P
rote
ction Fault state (if so programmed)
DeviceLogix Warning
The E300 relay provides a DeviceLogix warning indication if:
No trip currently exists
The DeviceLogix program activates the DeviceLogix Warning bit
If
the E300 relay warns on a DeviceLogix program, the following occurs:
The TRIP/WARN LED flashes a yellow 3-long / 3-short blink pattern
Bit 2 in Control Warning Status (Parameter 13) sets to 1
IMPORTANT
The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
Output PT00 Protection Fault Action (Parameter 304)
Output PT00 Protection Fault Value (Parameter 305)
Output PT01 Protection Fault Action (Parameter 310)
Output PT01 Protection Fault Value (Parameter 311)
Output PT02 Protection Fault Action (Parameter 316)
Output PT02 Protection Fault Value (Parameter 317)
Output Digital Module 1 Protection Fault Action (Parameter 322)
Output Digital Module 1 Protection Fault Value (Parameter 323)
Output Digital Module 2 Protection Fault Action (Parameter 328)
Output Digital Module 2 Protection Fault Value (Parameter 329)
Output Digital Module 3 Protection Fault Action (Parameter 334)
Output Digital Module 3 Protection Fault Value (Parameter 335)
Output Digital Module 4 Protection Fault Action (Parameter 340)
Output Digital Module 4 Protection Fault Value (Parameter 342)
