Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 635
Parameter List Appendix B
Device Monitor
(continued)
29 StartsCounter Number of starts UINT 2 1 0 65535 0
30 Starts Available Number of Starts
Available
USINT 1 1 0 120 0
31 TimeToStart The Time to Start UINT 2 1 0 3600 0
Seconds
32 Ye ar Virtual RTC Year UINT 2 1 0 9999 0
33 Month Virtual RTC Month UINT 2 1 0 12 0
34 Day Virtual RTC Day UINT 2 1 0 31 0
35 Hour Virtual RTC Hour UINT 2 1 0 23 0
36 Minute Virtual RTC Minute UINT 2 1 0 59 0
37 Second Virtual RTC Second UINT 2 1 0 59 0
38 InvaldCfgParam Number of
incorrectly
configured
parameter
UINT 2 1 0 9999 0
39 InvaldCfgCause Description of error USINT 1 1 0=NoError
1=ValueOverMax
2=Value UnderMin
3=IllegalValue
4=L3CurrentDetected
5=CopyCat Error
6-50 = Reserved
0
40 Reserved
41 Reserved
42 Reserved
Current Monitor 43 L1Current I.L1Current The actual L1
Phase Current.
DINT 4 100 0 2000000000 0 Amps
44 L2Current I.L2Current The actual L2
Phase Current.
DINT 4 100 0 2000000000 0 Amps
45 L3Current I.L3Current The actual L3
Phase Current.
DINT 4 100 0 2000000000 0 Amps
46 AverageCurrent I.AvgCurrent Average of Phase
Currents.
DINT 4 100 0 2000000000 0 Amps
47 L1PercentFLA L1 Current in %FLA UINT 2 10 0 10000 0 %
48 L2PercentFLA L2 Current in %FLA UINT 2 10 0 10000 0 %
49 L3PercentFLA L3 Current in %FLA UINT 2 10 0 10000 0 %
50 AvgPercentFLA I.AvgPercentFLA Average Current in
%FLA
UINT 2 10 0 10000 0 %
51 GFCurrent I.GroundFaultCurrent The Ground Fault
Current.
UINT 2 100 0 9999 0 Amps
52 CurrentImbal I.CurrentImbalance Percent Current
Imbalance
USINT 1 1 0 200 0 %
Voltage Monitor 53 L1toL2Voltage I.L1L2Voltage 3 Phase RMS
Voltage Line-Line
UINT 2 10 0 65535 0 Volt
54 L2toL3Voltage I.L2L3Voltage 3 Phase RMS
Voltage Line-Line
UINT 2 10 0 65535 0 Volt
55 L3toL1Voltage I.L3L1Voltage 3 Phase RMS
Voltage Line-Line
UINT 2 10 0 65535 0 Volt
56 AvgVoltageLtoL I.AvgLLVoltage Average RMS
Voltage Line-Line
UINT 2 10 0 65535 0 Volt
57 L1toNVoltage 3 Phase RMS
Voltage Line-
Neutral
UINT 2 10 0 65535 0 Volt
58 L2toNVoltage 3 Phase RMS
Voltage Line-
Neutral
UINT 2 10 0 65535 0 Volt
59 L3toNVoltage 3 Phase RMS
Voltage Line-
Neutral
UINT 2 10 0 65535 0 Volt
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
