Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 637
Parameter List Appendix B
Energy Monitoring
(Continued)
89 kVARhCon10E-3 Total Reactive
Energy Consumed
(kVARh) Word
10^-3
INT 2 1 -999 999 0
90 kVARhGen10E9 Total Reactive
Energy Generated
(kVARh) Word
10^9
INT 2 1 -999 999 0
91 kVARhGen10E6 Total Reactive
Energy Generated
(kVARh) Word
10^6
INT 2 1 -999 999 0
92 kVARhGen10E3 Total Reactive
Energy Generated
(kVARh) Word
10^3
INT 2 1 -999 999 0
93 kVARhGen10E0 Total Reactive
Energy Generated
(kVARh) Word
10^0
INT 2 1 -999 999 0
94 kVARhGen10E-3 Total Reactive
Energy Generated
(kVARh) Word
10^-3
INT 2 1 -999 999 0
95 kVARhNet10E9 Total Reactive
Energy Net
(kVARh) Word
10^9
INT 2 1 -999 999 0
96 kVARhNet10E6 Total Reactive
Energy Net
(kVARh) Word
10^6
INT 2 1 -999 999 0
97 kVARhNet10E3 Total Reactive
Energy Net
(kVARh) Word
10^3
INT 2 1 -999 999 0
98 kVARh Net 10E0 Total Reactive
Energy Net
(kVARh) Word
10^0
INT 2 1 -999 999 0
99 kVARhNet10E-3 Total Reactive
Energy Net
(kVARh) Word
10^-3
INT 2 1 -999 999 0
100 kVAhTimes10E9 Total Apparent
Energy (kVAh)
Word 10^9
INT 2 1 -999 999 0
101 kVAhTimes10E6 Total Apparent
Energy (kVAh)
Word 10^6
INT 2 1 -999 999 0
102 kVAhTimes10E3 Total Apparent
Energy (kVAh)
Word 10^3
INT 2 1 -999 999 0
103 kVAhTimes10E0 Total Apparent
Energy (kVAh)
Word 10^0
INT 2 1 -999 999 0
104 kVAhTimes10E-3 Total Apparent
Energy (kVAh)
Word 10^-3
INT 2 1 -999 999 0
105 kWDemand Real Power
Demand
DINT 4 1000 -
2000000000
2000000000 0 kW
106 MaxkWDemand Maximum Real
Power Demand
DINT 4 1000 -
2000000000
2000000000 0 kW
107 VARDemand Reactive Power
Demand
DINT 4 1000 -
2000000000
2000000000 0 kVAR
108 MaxVARDemand Maximum Reactive
Demand
DINT 4 1000 -
2000000000
2000000000 0 kVAR
109 VADemand Apparent Power
Demand
DINT 4 1000 0 2000000000 0 kVA
110 MaxVADemand Maximum
Apparent Power
Demand
DINT 4 1000 0 2000000000 0 kVA
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
