686 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Appendix D EtherNet/IP Information
Instance 2
The following table summarizes Attribute 3 Format:
Table 599 - Instance 2 — Basic Overload Output Assembly from ODVA Profile
Table 600 - Instance 2 Attributes
Instance 50
The following table summarizes Attribute 3 Format:
Table 601 - Instance 50 — Basic Overload Input Assembly from ODVA Overload Profile
Table 602 - Instance 50 Attributes
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Fault Reset
Attribute ID Access Rule Member Index Name Data Type Value
1 Get Number of Members in Member List UINT 2
2Get
Member List Array of STRUCT
0
Member Data Description UINT 2
Member Path Size UINT 0
Member Path Packed EPATH
1
Member Data Description UINT 1
Member Path Size UINT 12
Member Path Packed EPATH 6BH and “Fault Reset
3 Set Data UINT See data format above
4Get Size UINT1
100 Get Name SHORT_STRING Trip Reset Cmd”
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Tripped
Attribute ID Access Rule Member Index Name Data Type Value
1 Get Number of Members in Member List UINT 1
2Get
Member List Array of STRUCT
0
Member Data Description UINT 1
Member Path Size UINT 8
Member Path Packed EPATH 67H and “Tripped”
3 Get Data UINT See data format above
4Get Size UINT1
100 Get Name SHORT_STRING “Trip Status”
