EtherNet/IP Information Appendix D
The table below lists Fault Codes, Fault Text, and Fault Help Strings.
Table 651 - Fault Codes, Fault Text, and Fault Help Strings
Fault Code Fault Text Help Text
0 No Fault No Fault Conditions Detected
1 OverloadTrip Motor current overload condition
2 PhaseLossTrip Phase current Loss detected in one of the motor phases
3 GroundFaultTrip Power conductor or motor winding is shorting to ground
4 StallTrip Motor has not reached full speed by the end of Stall Enable Time
5 JamTrip Motor current has exceed the programmed jam trip level
6 UnderloadTrip Motor current has fallen below normal operating levels
7 Current Imbal Phase to phase current imbalance detected
8 L1UnderCurrTrip L1Current was below L1 Undercurrent Level longer than Trip Delay
9 L2UnderCurrTrip L2Current was below L2 Undercurrent Level longer than Trip Delay
10 L3UnderCurrTrip L3Current was below L3 Undercurrent Level longer than Trip Delay
11 L1OverCurrenTrip L1 Current was over L1 Overcurrent Level longer than Trip Delay
12 L2OverCurrenTrip L2 Current was over L2 Overcurrent Level longer than Trip Delay
13 L3OverCurrenTrip L3 Current was over L3 Overcurrent Level longer than Trip Delay
14 L1LineLossTrip L1 Current Lost for longer than the L1 Loss Trip Delay
15 L2LineLossTrip L2 Current Lost for longer than the L2 Loss Trip Delay
16 L3LineLossTrip L3 Current Lost for longer than the L3 Loss Trip Delay
17 UnderVoltageTrip Line to Line Under-Voltage condition detected
18 OverVoltageTrip Line to Line Over-Voltage condition detected
19 VoltageUnbalTrip Phase to phase voltage imbalance detected
20 PhaseRotationTrp The unit detects the supply voltage phases are rotated
21 UnderFreqTrip Line voltage frequency is below trip level
22 OverFreqTrip Line voltage frequency has exceeded trip level
23 Fault23
24 Fault24
25 Fault25
26 Fault26
27 Fault27
28 Fault28
29 Fault29
30 Fault30
31 Fault31
32 Fault32
33 UnderKWTrip Total Real Power(kW)is below trip level
34 OverKWTrip Total Real Power(kW)has exceeded trip level
35 UnderKVARConTrip Under Total Reactive Power Consumed (+kVAR) condition detected
36 OverKVARConTrip Over Total Reactive Power Consumed (+kVAR) condition detected
37 UnderKVARGenTrip Under Total Reactive Power Generated (-kVAR) condition detected
38 OverKVARGenTrip Over Total Reactive Power Generated (-kVAR) condition detected
39 UnderKVATrip Total Apparent Power (VA or kVA or MVA) is below trip level
40 OverKVATrip Total Apparent Power (VA or kVA or MVA) exceeded trip level
41 UnderPFLagTrip Under Total Power Factor Lagging (-PF) condition detected
42 OverPFLagTrip Over Total Power Factor Lagging (-PF) condition detected
43 UnderPFLeadTrip Under Total Power Factor Leading (+PF) condition detected
44 OverPFLeadTrip Over Total Power Factor Leading (+PF) condition detected
45 Fault45
46 Fault46
