Rockwell Automation Publication 193-UM015E-EN-P - October 2015 721
EtherNet/IP Information Appendix D
38 OverKVARGenWarn Over Reactive Power Generated (-kVAR) condition detected
39 Under Power kVA Total Apparent Power (kVA) is below warning level
40 Over Power kVA Total Apparent Power (kVA) exceeded warning level
41 Under PF Lagging Under Total Power Factor Lagging (-PF) condition detected
42 Over PF Lagging Over Total Power Factor Lagging (-PF) condition detected
43 Under PF Leading Under Total Power Factor Leading (+PF) condition detected
44 Over PF Leading Over Total Power Factor Leading (+PF) condition detected
45 Warning 45
46 Warning 46
47 Warning 47
48 Warning 48
49 Warning49
50 PTC PTC input indicates that the motor stator windings overheated
51 DLXWarning DeviceLogix defined warning was generated
52 Warning52
53 Warning53
54 Warning54
55 Warning55
56 ConfigWarning Invalid parameter config. See parameters 38-39 for details
57 Warning57
58 DLXFBTimeoutWarn DeviceLogix Feedback Timeout Trip was detected
59 Warning59
60 PM Starts Number of Starts Warning Level Exceeded
61 PM Oper Hours Operating Hours Warning Level Exceeded
62 Warning62
63 Warning63
64 Warning64
65 InAnMod1Ch00Warn Input Channel 00 on Analog Module 1 exceeded its Warning Level
66 InAnMod1Ch01Warn Input Channel 01 on Analog Module 1 exceeded its Warning Level
67 InAnMod1Ch02Warn Input Channel 02 on Analog Module 1 exceeded its Warning Level
68 InAnMod2Ch00Warn Input Channel 00 on Analog Module 2 exceeded its Warning Level
69 InAnMod2Ch01Warn Input Channel 01 on Analog Module 2 exceeded its Warning Level
70 InAnMod2Ch02Warn Input Channel 02 on Analog Module 2 exceeded its Warning Level
71 InAnMod3Ch00Warn Input Channel 00 on Analog Module 3 exceeded its Warning Level
72 InAnMod3Ch01Warn Input Channel 01 on Analog Module 3 exceeded its Warning Level
73 InAnMod3Ch02Warn Input Channel 02 on Analog Module 3 exceeded its Warning Level
74 InAnMod4Ch00Warn Input Channel 00 on Analog Module 4 exceeded its Warning Level
75 InAnMod4Ch01Warn Input Channel 01 on Analog Module 4 exceeded its Warning Level
76 InAnMod4Ch02Warn Input Channel 02 on Analog Module 4 exceeded its Warning Level
77 Warning77
78 Warning 78
79 Warning 79
80 Warning 80
81 DigitalMod1Warn Digital Expansion Module 1 is not operating properly
82 DigitalMod2Warn Digital Expansion Module 2 is not operating properly
83 DigitalMod3Warn Digital Expansion Module 3 is not operating properly
84 DigitalMod4Warn Digital Expansion Module 4 is not operating properly
85 AnalogMod1Warn Analog Expansion Module 1 is not operating properly
86 AnalogMod2Warn Analog Expansion Module 2 is not operating properly
Warning
Code
Warning Text Warning Help Text
