MT8852B Specification
A-10 PN: 13000-00205 Rev. N MT8852B Operation Manual
Measurement
configuration
DUT configured to receive Test Reference Packets.
Packet payload: PRBS9
Full support of Dirty Transmitter as defined in test specification
Displayed results Receiver PER. Requires DUT to support HCI UART or USB or
2-Wire interface for automated PER results.
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Output power range 0 dBm to -90 dBm, resolution 0.1 dB
Output power accuracy ± 1 dB, 0 dBm to -80 dBm
BLE Maximum input
signal level
RCV-LE/CA/BV-06-C (BLE), RCV-LE/CA/BV-18-C (BLE Stable)
RCV-LE/CA/BV-12-C (2LE), RCV-LE/CA/BV-24-C (2LE Stable)
Measurement
configuration
DUT configured to receive Test Reference Packets.
Packet payload: PRBS9
Displayed results Receiver PER. Requires DUT to support HCI UART or USB or
2-Wire interface for automated PER results.
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Output power range 0 dBm to -90 dBm, resolution 0.1 dB
Output power accuracy
accuracy
± 1 dBm, 0 dBm to -80 dBm
BLE PER report
integrity
RCV-LE/CA/BV-07-C (BLE), RCV-LE/CA/BV-19-C (BLE Stable),
RCV-LE/CA/BV-13-C (2LE), RCV-LE/CA/BV-25-C (2LE Stable),
RCV-LE/CA/BV-30-C (BLR S=2), RCV-LE/CA/BV-31 (BLR S=8),
RCV-LE/CA/BV-32-C (BLR S=2 Stable),
RCV-LE/CA/BV-33-C (BLR S=8 Stable)
Measurement
configuration
DUT configured to receive Test Reference Packets.
Packet payload: PRBS9
CRC corruption: Alternate packets
Number of test packets: Random [100 RND 1500]
Displayed results Receiver PER. Requires DUT to support HCI UART or USB or
2-Wire interface for automated PER results.
Number of measurement
frequencies
One, default to RF Test Specification or user defined
Output power range 0 dBm to -90 dBm, resolution 0.1 dB
Output power accuracy ± 1 dBm, 0 dBm to -80 dBm
MT8852B Signal
Generator
Frequency
