MT8852B Specification
MT8852B Operation Manual PN: 13000-00205 Rev. N A-9
Displayed results Frequency deviation:
f1max,
f2max, (BLE and 2LE)
f1avg,
f2avg, (BLE and 2LE)
f2avg / f1avg ratio, (BLE and 2LE)
%f2max, > 185 kHz (BLE)
%f2max, > 370 kHz (2LE)
Number of measurement
frequencies
Three, default to RF Test specification or user defined
Measurement range RF input: +20 dBm to -35 dBm
Deviation: 0 Hz to 500 kHz peak (except 2LE)
Resolution Deviation: 1 kHz
Accuracy 1% for modulation index 0.5
BLE Carrier frequency
offset and drift
TRM-LE/CA/BV-06-C (BLE), TRM-LE/CA/BV-12-C (2LE),
TRM-LE/CA/BV-14-C (BLR S=8)
Measurement
configuration
DUT configured to transmit Test Reference Packets.
Packet payload: 10101010 (BLE and 2LE)
Packet payload: 11111111 (BLR S=8)
Displayed results Carrier frequency error
Frequency drift
Drift rate
Initial drift rate
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Measurement range RF input: +20 dBm to -35 dBm
Frequency: 500 kHz
Frequency Resolution 1 kHz
Accuracy 500 Hz ± Frequency standard
BLE Receiver
sensitivity
RCV-LE/CA/BV-01-C (BLE), RCV-LE/CA/BV-14-C (BLE Stable),
RCV-LE/CA/BV-08-C (2LE), RCV-LE/CA/BV-20-C (2LE Stable),
RCV-LE/CA/BV-26-C (BLR S=2), RCV-LE/CA/BV-27-C (BLR S=8),
RCV-LE/CA/BV-32-C (BLR S=2 Stable),
RCV-LE/CA/BV-33-C (BLR S=8 Stable)
