MT8852B Specification
A-8 PN: 13000-00205 Rev. N MT8852B Operation Manual
Measurement
configuration
Hopping: OFF and ON, user selectable
Modulations: /4DQPSK and 8DPSK
Packet type: 2-DH1, 3, 5 and 3-DH1, 3, 5
Number of bits: default 1.6 million (user editable)
Loopback only
Displayed results Overall BER (displayed in exponential format)
Number of bits in error
Number of packets sent by test set
Number of packets received in error by EUT
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Output power range 0 to –90 dBm, resolution 0.1 dB
Output power accuracy ±1 dB, 0 dBm to –80 dBm
Low Energy
Measurements
BLE measurements made in compliance with Bluetooth RF test
specification RF-PHY.TS/5.0.0.
BLE Output power TRM-LE/CA/BV-01-C
Measurement
configuration
DUT configured to transmit Test Reference Packets.
Packet payload: PRBS9
Displayed results Average power
Peak to average power
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Measurement range +22 dBm to -50 dBm average power (+23 dBm peak power)
Resolution 0.1 dB
Accuracy +20 dBm to -35 dBm, ±1.0 dB
+22 dBm to +20 dBm, ±1.5 dB
BLE Modulation
characteristics
TRM-LE/CA/BV-05-C (BLE), TRM-LE/CA/BV-09-C (BLE Stable)
TRM-LE/CA/BV-10-C (2LE), TRM-LE/CA/BV-11-C (2LE Stable)
TRM-LE/CA/BV-13-C (BLR S=8)
Measurement
configuration
DUT configured to transmit Test Reference Packets.
Packet payload: 10101010 and 11110000 (BLE and 2LE)
Packet payload: 11111111 (BLR S=8)
