MT8852B Specification
MT8852B Operation Manual PN: 13000-00205 Rev. N A-7
Measurement
configuration
Hopping mode: OFF and ON, user selectable
Modulations: /4DQPSK and 8DPSK
Packet type: 2-DH1, 3, 5 and 3-DH1, 3, 5.
Bit threshold control: Threshold 1, 1.6 million bits, Threshold 2, 16
million bits (user editable)
Loopback only
Dirty transmitter (as defined in RF test spec): ON or OFF, user
selectable
Displayed results Overall BER (displayed in exponential format)
Number of bits in error
Number of packets sent by test set
Number of packets received in error by EUT
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Output power range 0 to –90 dBm, resolution 0.1 dB
Output power accuracy ±1 dB, 0 dBm to –80 dBm
EDR BER Floor
Performance
RCV/CA/BV-08-C
Measurement
configuration
Modulations: /4DQPSK and 8DPSK
Packet type: 2-DH1, 3, 5 and 3-DH1, 3, 5
Bit threshold control: Threshold 1, 8 million bits, Threshold 2, 160
million bits (user editable)
Loopback only
Hopping: OFF and ON, user selectable
Displayed results Overall BER (displayed in exponential format)
Number of bits in error
Number of packets sent by test set
Number of packets received in error by EUT
Number of measurement
frequencies
Three, default to RF Test Specification or user defined
Output power range 0 to –90 dBm, resolution 0.1 dB
Output power accuracy ±1 dB, 0 dBm to –80 dBm
EDR maximum Input
Level
RCV/CA/BV-10-C
