MT8852B Specification
A-12 PN: 13000-00205 Rev. N MT8852B Operation Manual
GFSK modulation
Deviation measurement
range
0 to 350 kHz peak
Accuracy 1% for Modulation Index = 0.32
EUT Control Interface
RS232 HCI commands The EUT control interface provides RS232 HCI commands to the
EUT through a standard RS-232 interface. The interface meets the
requirements of the Bluetooth specification for HCI UART transport
layer. A RS232 cable is supplied.
USB HCI commands The EUT control interface provides USB HCI commands to the EUT
through a standard USB interface. The interface meets the
requirements of the Bluetooth specification section H:2. A USB
cable is supplied.
USB->RS232 HCI
commands
For use with EUTs fitted with USB->RS232 FTDI chips.
2-Wire control For test control of Bluetooth low energy devices the EUT control
interface supports the 2-Wire specification
Characteristic/Parameter Specification
Audio Specifications
Number of SCO
channels supported
3
Codec air interfaces
supported
CVSD, A-Law, µ-Law
Frequency response (–3 dB) measured CODEC in to CODEC out: 160 Hz –3.5 kHz.
Measured with 50 source impedance and 10 M load impedance
Maximum input / output
signal level
3.4 Vpk-pk = 1.2 V RMS
Distortion/noise A law: typical –37 dB at 1 kHz, 1 V RMS
µ law: typical –37 dB at 1 kHz, 1 V RMS
CVSD: typical –30 dB at 300 Hz, 1 V RMS
Input/Output connectors 3.5 mm audio jack plugs (one for each SCO channel)
Input impedance 20 k
Minimum output load 600
Internal audio source 1 kHz fixed frequency
AFH (Option 15) Supported in ACL and SCO connections
Displays Active channel vs. time, FER vs. time
Other features ACL connection timer, resolution 1 ms
Frequency Standard
Frequency 10 MHz
Temperature Stability ±0.5 ppm, –10ºC to +85ºC
