MT8852B Specification
MT8852B Operation Manual PN: 13000-00205 Rev. N A-13
Aging (1st year) ±1.0 ppm
Aging (over 10 years) ±2.5 ppm, including year 1
Rear Panel Connectors
External frequency
standard input
Rear panel BNC socket, 50 1 volt
Output 1 TTL output for TX ON, TX DATA, RX DATA, and correlator
Output 2 TTL output for RX ON, TX DATA, RX DATA, and correlator
Input 1 For service use only
GPIB
IEE 488.2 Offers full instrument control as standard
RS232
RS232 Offers full instrument control as standard
General
Rated Voltage 100 to 120 Vac / 200 to 240 Vac
Rated Frequency 50/60 Hz
Power Consumption 150 VA Max
Environmental
Operating temperature 5 to +40ºC
Operating humidity 20% to 75%
Safety Complies with IEC 61010-1
EMC Conforms to the protection requirements of EEC Council Directive
2014/30/EU
Size and Mass
Dimensions 216.5 mm x 88 mm x 380 mm
Mass <3.8 kg
