DL205 Analog Manual, 7th Edition Rev. D
6-3
Chapter 6: F2-04RTD 4-Channel RTD Input
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
Input Specifications
The following table provides the specifications for the F2-04RTD Input Module. Review
these specifications to make sure the module meets your application requirements.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
Input Specifications
Number of Channels
4, differential inputs
Input Ranges
Pt100 -200.0°C – 850.0°C (-328°F – 1562°F)
PT1000 -200.0°C – 595.0°C (-328°F – 1103°F)
jPt100 -38.0°C – 450.0°C (-36°F – 842°F)
Cu10q -200.0°C – 260.0°C (-328°F – 500°F)
Cu25q -200.0°C – 260.0°C (-328°F – 500°F)
Resolution
±0.1°C, ±0.1°F (±3276.7)
Absolute Maximum Ratings
Fault Protected Inputs to ±50VDC
Converter Type
Charge Balancing, 24 bit
Sampling Rate
160ms per channel
Linearity Error (End to End)
±0.05°C maximum, ±0.01°C typical
PLC Update Rate
4 channels/scan max. 240/250–1/260 CPU
1 channel/scan max. 230 CPU
Temperature Drift
5ppm /°C maximum
Maximum Inaccuracy
±1°C
RTD Excitation Current
200µA
Common Mode Range
0–5 VDC
Notch Filter
>100 dB notches @ 50/60Hz
f
-3dB
= 13.1Hz
Digital Input Points Required
32 (X) input points
15 binary data bits, 1 sign bit, 2 channel ID bits
4 fault bits
Power Budget Requirements
90mA @ 5VDC (supplied by base)
Operating Temperature
0 – 60°C (32 – 140°F)
Storage Temperature
-20 – 70°C (-4 – 158°F)
Relative Humidity
5 – 95% (non-condensing)
Environmental Air
No corrosive gases permitted
Vibration
MIL STD 810C 514.2
Shock
MIL STD 810C 516.2
Noise Immunity
NEMA ICS3-304
