AutomationDirect DL205 Manual

DL205 Analog Manual, 7th Edition Rev. D
14-3
Chapter 14: F2-4AD2DA 4-Ch. In / 2-Ch. Out Analog Combination
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
NOTE: One count in the specifications table is equal to one least significant bit of the analog data value (1 in 4096)
Combination Analog Configuration Requirements
The F2-4AD2DA Analog module requires 16 discrete input and 16 discrete output points.
The module can be installed in any slot of a DL205 system, except when the DL230 CPU
is used. The available power budget may also be a limiting factors. Check the DL205 PLC
User Manual for the particular model of CPU and I/O base being used for more information
regarding power budget and number of local, local expansion or remote I/O points.
Output Specifications
Number of Output Channels
2, single ended (one common)
Range
4–20 mA
Resolution
12 bit (1 in 4096)
Peak Withstanding Voltage
75 VDC, current outputs
External Load Resistance
0q minimum, current outputs
Loop Supply Voltage Range
18–30 VDC, current outputs
Maximum Load / Power Supply
910q / 24V, 620q / 18V, 1200q / 30V, current outputs
Linearity Error (best fit)
±1 count (± 0.025% of full scale) maximum
Settling Time
100μs maximum (full scale change)
Maximum Inaccuracy
±0.1% @ 25°C (77°F)
±0.3% 0–60°C (32–140°F)
Full Scale Calibration Error
±5 counts @ 20mA current output
Output Calibration Error
±3 counts @ 4mA current output
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
General Module Specifications
Digital Input and Output Points Required
16 point (X) Inputs
16 point (Y) Outputs
PLC Update Rate
4 input channels/scan max. (D2-240/250-1–1/260 CPU)
2 output channels/scan max. (D2-240/250-1–1/260 CPU)
1 input and 1 output channel/scan max. (D2-230 CPU)
Power Budget Requirement
60mA @ 5VDC (supplied by the base)
External Power Supply Requirement
24VDC, 80mA max. plus 20mA/ loop output
Accuracy vs. Temperature
±45 ppm / °C full scale calibration range
(including maximum offset change).
Operating Temperature
0–60°C (32–140°F)
Storage Temperature
–20–70°C (- 4–158°F)
Relative Humidity
5–95% (non-condensing)
Environmental Air
No corrosive gases permitted
Vibration
MIL STD 810C 514.2
Shock
MIL STD 810C 516.2
Noise Immunity
NEMA ICS3-304
