AutomationDirect DL205 Manual

DL205 Analog Manual, 7th Edition Rev. D
10-3
Chapter 10: F2-08DA-1, 8-Channel Analog Current Output
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
The following tables provide the specifications for the F2–08DA–1 Analog Output Module.
Review these specifications to make sure the module meets your application requirements.
NOTE: One count in the specifications table is equal to one least significant bit of the analog data value (1 in 4096)
Output Specifications
Number of Channels
8, single-ended
Output Range
4–20 mA
Resolution
12 bit (1 in 4096)
Output Type
Current sinking and current sourcing
Maximum Loop Supply
30VDC
Source Load
0 – 400q (for loop power 18 – 30V)
Sink Load
0 – 600q / 18V, 900q / 24V, 1200q / 30V
Total Load (sink plus source)
600q / 18V, 900q / 24V, 1200q / 30V
Linearity Error (end to end)
±2 counts (±0.050% of full scale) maximum
Conversion Settling Time
400µs maximum (full scale change)
Full-scale Calibration Error
±12 counts maximum, sinking (any load)
±12 counts maximum, sourcing (125q load)
±18 counts maximum, sourcing (250q load)
±26 counts maximum, sourcing (400q load)
Offset Calibration Error
±9 counts maximum, sinking (any load)
±9 counts maximum, sourcing (125q load)
±11 counts maximum, sourcing (250q load)
±13 counts maximum, sourcing (400q load)
Maximum Full Scale Inaccuracy @ 0–60°C
0.5% sinking (any load) & sourcing (125q load )
0.64% sourcing (250q load )
0.83% sourcing (400q load)
Maximum Full Scale Inaccuracy @ 0–25°C
(includes all errors & temperature drift)
0.3% sinking (any load) & sourcing (125q load )
0.44% sourcing (250q load )
0.63% sourcing (400q load)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
General Specifications
PLC Update Rate
8 channel per scan maximum
Digital Outputs /
Output Points Required
12 binary data bits, 3 channel ID bits, 1 output enable bit /
16 (Y) output points required
Power Budget Requirement
30mA @ 5VDC (supplied by the base)
External Power Supply
18–30 VDC, 50mA plus 20mA / output loop, class 2
Operating Temperature
0–60°C (32–140°F)
Storage Temperature
-20–70°C (-4–158°F)
Relative Humidity
5–95% (non-condensing)
Environmental air
No corrosive gases permitted
Vibration
MIL STD 810C 514.2
Shock
MIL STD 810C 516.2
Noise Immunity
NEMA ICS3-304
