AutomationDirect DL205 - Output Specifications; General Specifications

DL205 Analog Manual, 7th Edition Rev. D
8-3
Chapter 8: F2-02DA-1, F2-02DA-1L, 2-Channel Analog Current Output
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
The following tables provide the specifications for the F2–02DA –1 and F2-02DA-1L Analog
Output Modules. Review these specifications to make sure the module meets your application
requirements.
NOTE: One count in the specifications table is equal to one least significant bit of the analog data value (1 in 4096)
Output Specifications
Number of Channels
2
Output Range
4–20 mA
Resolution
12 bit (1 in 4096)
Output Type
Single ended, 1 common
Maximum Loop Supply
30VDC
Peak Output Voltage
40VDC (clamped by transient voltage suppressor)
Load Impedance
0q minimum
Maximum Load / Power Supply
620q / 18V, 910q / 24V, 1200q / 30V
Linearity Error (end to end)
±1 count (±0.025% of full scale) maximum
Conversion Settling Time
100µs maximum (full scale change)
Full-scale Calibration Error
(offset error included)
±5 counts maximum, 20mA @ 25°C (77°F)
Offset Calibration Error
±3 counts maximum, 4mA @ 25°C (77°F)
Maximum Inaccuracy
0.1% @ 25°C (77°F)
0.3% @ 0–60°C (32–140°F)
Accuracy vs. Temperature
±50ppm /°C full scale calibration change
(including maximum offset change of 2 counts)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
General Specifications
PLC Update Rate
1 channel per scan maximum (D2-230 CPU)
2 channels per scan maximum (D2-240/250-1/260 CPUs)
Digital Outputs
Output Points Required
12 binary data bits, 2 channel ID bits
16 (Y) output points required
Power Budget Requirement
40mA @ 5VDC (supplied by the base)
External Power Supply
F2-02DA-1: 24VDC, 60mA
F2-02DA-1L: 12VDC, 70mA
(add 20mA for each current loop used)
Operating Temperature
0–60°C (32–140°F)
Storage Temperature
-20–70°C (-4–158°F)
Relative Humidity
5–95% (non-condensing)
Environmental air
No corrosive gases permitted
Vibration
MIL STD 810C 514.2
Shock
MIL STD 810C 516.2
Noise Immunity
NEMA ICS3-304
