DL205 Analog Manual, 7th Edition Rev. D
7-3
Chapter 7: F2-04THM, 4-Channel Thermocouple Input
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
B
C
D
NOTE: R Wide range is available only on modules with date code 0410E2 and later.
Module Calibration
The F2-04THM module requires no calibration. The module automatically calibrates every
five seconds, which removes offset and gain errors. For each thermocouple type, the temperature
calculation and linearization performed by the microprocessor is accurate to within 0.01°C.
Thermocouple Input Configuration Requirements
The F2-04THM module requires 32 discrete input points from the CPU. The module can be
installed in any slot of a DL205 system. The limitations on the number of analog modules are:
• For local and local expansion systems, the available power budget and number of discrete I/O
points.
• For remote I/O systems, the available power budget and number of remote I/O points.
Check the user manual for the particular model of CPU and I/O base being used for more
information regarding power budget and number of local, local expansion or remote I/O
points.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
b
C
D
Thermocouple Specifications
Input Ranges
Type J -190–760ºC (-310–1400ºF)
Type K -150–1372ºC (-238–2502ºF)
Type E -210–1000ºC (-346–1832ºF)
Type R 65–1768ºC (149–3214ºF)
Type S 65–1768ºC (149–3214ºF)
Type T -230–400ºC (-382–752ºF)
Type B 529–1820ºC (984–3308ºF)
Type N -70–1300ºC (-94–2372ºF)
Type C 65–2320ºC (149–4208ºF)
Display Resolution
±0.1ºC or ±0.1ºF
Cold Junction Compensation
Automatic
Warm-Up Time
30 minutes typically ±1ºC repeatability
Linearity Error (End to End)
±1ºC maximum, ±0.5ºC typical
Maximum Inaccuracy
±3ºC (excluding thermocouple error)
Voltage Input Specifications
Voltage Ranges
Voltage: 0-5V, ±5V, 0-156.25 mV, ±156.25 mVDC,
Resolution
16 bit (1 in 65535)
Full Scale Calibration Error
(Offset Error Included)
±13 count typical, ±33 maximum
Offset Calibration Error
±1 count maximum @ 0V input
Linearity Error (End to End)
±1 count maximum
Maximum Inaccuracy
±0.02% @ 25ºC (77ºF)
