AutomationDirect DL205 Manual

DL205 Analog Manual, 7th Edition Rev. D
4-3
Chapter 4: F2-08AD-1, 8-Channel Analog Current Input
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
The following tables provide the specifications for the F2-08AD-1 Analog Input Module.
Review these specifications to make sure the module meets your application requirements.
NOTE: Values in parenthesis with an asterisk are for older modules with two circuit board design and date codes
0609B5 or previous. Values not in parenthesis are for single circuit board models with date code 0709C1 or above.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
General Specifications
PLC Update Rate
1 channel per scan maximum (DL230 CPU)
4 channels per scan maximum (DL240/250-1/260 CPU)
Data Acquisition Time
3 ms/channel (asynchronous)
Digital Inputs
Input points required
12 binary data bits, 3 channel ID bits, 1 broken transmitter
detection bit
16 point (X) input module
Power Budget Requirement
100 mA (*50 mA maximum, 5 VDC (supplied by base)
External Power Supply
5 mA (*80 mA max., 10–30 VDC (*18–26.4 VDC)
Operating Temperature
0–60! C (32!–140! F)
Storage Temperature
-20–70! C (-4!–158! F)
Relative Humidity
5–95% (non-condensing)
Environmental Air
No corrosive gases permitted
Vibration
MIL STD 810C 514.2
Shock
MIL STD 810C 516.2
Noise Immunity
NEMA ICS3-304
One count in the specification tables is equal to one least significant bit of the analog data value ( 1 in 4096).
Input Specifications
Number of Channels
4, single ended (one common)
Input Range
0–5 VDC, 0–10 VDC, W5V, w10V
Resolution
12 bit (1 in 4096) unipolar (0–4096)
13 bit (1 in 8192) bipolar (-4095 – +4095)
Common Mode Rejection
- 50 db at 800Hz
Step Response
8.2ms (*10ms) to 95% of full step change
Crosstalk
-70 db, 1 count maximum
Active Low-pass Filtering
-3 db at 80Hz, 2 poles (-12 db per octave)
Input Impedance
Greater than 20Mq
Absolute Maximum Ratings
-75 – +75 VDC
Converter Type
Successive approximation
Linearity Error (End to End)
± 1 count (0.025% of span) maximum unipolar
± 2 counts maximum bipolar
Input Stability
± 1 count
Full Scale Calibration Error
(Offset error included)
± 3 counts maximum
Offset Calibration Error
± 1 count maximum (0V input)
Maximum Inaccuracy
± 0.1% @ 25°C (77°F)
± 0.3% 0–60°C (32–140°F)
Accuracy vs. Temperature
± 50ppm / °C full scale calibration change (including maximum
offset change of 2 counts)
