DL205 Analog Manual, 7th Edition Rev. D
4-2
Chapter 4: F2-08AD-1, 8-Channel Analog Current Input
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
Module Specifications
NOTE: A re-designed F2-08AD-1 with a single circuit board design was released in 2009. The jumper link location is different. See
Setting the Module Jumpers on page 4-6. Also, some specifications were changed on page 4-3. Otherwise, the re-designed module
functions the same as the prior design.
The F2-08AD-1 Analog Input module provides several
hardware features:
• Analog inputs are optically isolated from the PLC logic.
• On-board 250 ohm, 1/2 watt precision resistors provide
substantial over-current-protection for 4-20mA current
loops.
• The module has a removable terminal block so the
module can be easily removed or changed without
disconnecting the wiring.
• With a DL240, DL250-1 and DL260 CPU, you can read
all channels in one scan.
Firmware Requirements:
To use this module with a D2-230 CPU the CPU must have
firmware version 1.6 or later. To use the pointer method of
writing values, D2-240 CPUs require firmware version 2.2
or later. All versions of the D2-250-1 and D2-260 CPU’s
firmware support this module and the pointer method.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
+24V
CH2+
CH4+
CH6+
CH8+
0V
CH1+
CH3+
CH5+
CH7+
F2-08AD-1
IN ANALOG
8CH
10-30VDC
5mA
ANALOG IN
4-20mA
+
2
4
V
C
H2+
C
H4+
C
H6+
C
H
8
+
0V
C
H1+
C
H
3
+
C
H
5
+
C
H7+
F2
-
08
AD-
1
IN
1
0-30VD
C
5
m
A
A
NAL
O
G
IN
4-
20
m
A
A
NAL
OG
A
8C
H
Analog Input Configuration Requirements
The F2-08AD-1 appears as a 16-point discrete input module and can be installed in any
slot of a DL205 system. The available power budget and discrete I/O points are the limiting
factors. For more information regarding power budget and number of local, local expansion
or remote I/O points, check the user manual for the particular CPU model and I/O base
being used
