The following tables provide a condensed version of the information needed to select the
appropriate module. The most important thing is to simply determine the number of channels
required and the signal ranges that must be supported. Once the parameters have been
determined, look in the specific chapter for the selected module to determine the installation
and operation requirements.
Analog Input Modules
Specification F2-04AD-1, (L) F2-04AD-2, (L) F2-08AD-1 F2-08AD-2
Channels 4 4 8 8
Input Ranges 4–20 mA
0–5V, 0–10V,
-5–+5V,
-10–+10V
4–20 mA
0–5V, 0–10V,
-5–+5V,
-10–+10V
Resolution 12 bit (1 in 4096)
12 bit (1 in 4096), and
13 bit (1 in 8192)
12 bit (1 in 4096)
12 bit (1 in 4096), and
13 bit (1 in 8192)
Input Type Single ended Single ended Single ended Single ended
Maximum Inaccuracy
w 0.5% at 25-C
(77-F),
w 0.65% at 0- - 60-C
(32- - - 140-F)
w 0.1% at 25-C
(77-F),
w 0.3% at 0- - 60-C
(32- - 140-F)
w 0.1% at 25-C
(77-F),
w 0.25% at 0- - 60-C
(32- - 140-F)
w 0.1% at 25-C
(77-F),
w 0.3% at 0- - 60-C
(32- - 140-F)
See Chapter... 2 3 4 5
Special Input
Specification F2-04RTD F2-04THM
Input Channels 4 4
Resolution 16 bit internal
16 bit voltage ranges
24 bit internal
Input Ranges
Pt100h, -200.0 - 850.0-C
(-328 - 1562-F)
Pt1000h, -200.0 - 595.0-C
(-328 - 1103-F)
Pt100h, -38.0 - 450.0-C
(-36 - 842-F)
Cu. 25h, Cu. 10h
-200.0 - 260.0-C
(-328 - 500-F)
Type J -190 - 760.0-C
E -210 - 1000.0-C
K -150 - 1372.0-C
R 65 - 1768.0-C
R Wide -0 - 1768.0-C
S 65 - 1768.0-C
T -230 - 400.0-C
B 529 - 1820.0-C
N -70 - 1300.0-C
C 65 - 2320.0-C
Input Type Differential Differential
Maximum Input
Inaccuracy
w 1.0-C
w 3.0-C Temperature
w 0.02% Voltage
See Chapter... 6 7
