DL205 Analog Manual, 7th Edition Rev. D
15-12
Chapter 15: F2-8AD4DA-1, 8-Ch. In / 4-Ch. Out Analog Current Combination
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
B
C
D
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
b
C
D
Input Data Bits
Depending upon the resolution selected, up to 16
bits of the input word represent the analog data in
binary format.
Bit Value Bit Value
0 1 8 256
1 2 9 512
2 4 10 1024
3 8 11 2048
4 16 12 4096
5 32 13 8192
6 64 14 16384
7 128 15 32768
The upper byte of the second input word
represents the broken transmitter detection bits for
use only with 4–20 mA input devices. The lower
byte is not usable by the programmer.
Output Data Bits
All 16 bits of the first output word represent the
analog data in binary format.
Bit Value Bit Value
0 1 8 256
1 2 9 512
2 4 10 1024
3 8 11 2048
4 16 12 4096
5 32 13 8192
6 64 14 16384
7 128 15 32768
The second output word is not usable by the
programmer.
X
3
7
--
1
5
LSB
Broken Transmitter Detection Bits (seocond input word)
V40402
Input Address #
X
57
X
56
X
55
X
54
X
53
X
52
X
51
X
50
X
47
....
X
40
Input Bit #
15 14 13 12 11 10 9 8 7 .... 0
BT for Channel #
8 7 6 5 4 3 2 1 n/a .... n/a
