AutomationDirect DL205 Manual

DL205 Analog Manual, 7th Edition Rev. D
15-4
Chapter 15: F2-8AD4DA-1, 8-Ch. In / 4-Ch. Out Analog Current Combination
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
B
C
D
NOTE: One count in the specifications table is equal to one least significant bit of analog data value (1 in
65536)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
b
C
D
Output Specifications
Number of Output Channels
4
Output Range
4–20 mA
Output Resolution
16 bit; 0.244 μA / bit
Output Type
Current sourcing at 20mA max.
Output Signal at Power-up & Power-down
≤4mA
External Load Resistance
0–750q
Maximum Inductive Load
1mH
Allowed Load Type
Grounded
Output Voltage Drop
6V max.; 1V min.
Max. Continuous Output Overload
Open circuit protected
Type of Output Protection
Electronically current limited to 20mA or less
PLC Output All Channel Update Time
4ms (local base)
Output Settling Time
0.5ms max.; 5μs min. (full scale change)
Output Ripple
0.005% of full scale
Accuracy vs. Temperature
±25 ppm/°C max. full scale calibration change (±0.0025%
of range/°C)
Output Stability and Repeatability
±1 LSB after 10 minute warm-up typical
Output Inaccuracy
0.1% of range maximum
Linearity Error (end to end)
±33 counts max. ( ±0.05% of full scale)
Monotonic with no missing codes
Full Scale Calibration Error
(not including offset error)
±0.07% of range maximum
Offset Calibration Error
±0.03% of range maximum
Crosstalk at DC, 50/60Hz
-70 dB or 0.025% of full scale
